Shears
Bonded CFRP carbon fibre shear brackets to reinforce existing structures
- Extend the service life of structures
- Simple, cost-effective solution
- Wide range of applications
- Minimal intervention on existing structure
Modulus of elasticity: 95 kN/mm2
Shears (Modulus E 95 kN/mm2)
| Type of angle | Length of short side (mm) | Length of long side (mm) | Width (mm) | Thickness (mm) |
| SS 4/20/50 | 200 | 500 | 40 | 2 |
| SS 4/30/70 | 300 | 700 | 40 | 2 |
| SS 4/50/100 | 500 | 1'000 | 40 | 2 |
| SS 4/80/150 | 800 | 1'500 | 40 | 2 |
Technical data
| Average value of the modulus of elasticity in the longitudinal direction of the fibres | 95 kN/mm2 |
| Tensile strength in the longitudinal direction of the fibres | > 1'350 N/mm2 |
| Elongation at break | > 1,3% |
| Glass transition temperature to EN 61006 | > +100°C |
| Density | 1'550 kg/m3 |
| Volumetric percentage of fibre | > 56% |
| Inside radius of curvature | 25 mm |
| Branch angle | 90° |
Advantages
- Control of reinforcement dimensioning
- Very low dead weight
- No corrosion
- Excellent fatigue behaviour
- Small footprint
Technical data
Find all the information about the Strong-Shears solution in its technical data sheet.
If you wish, you can also download the technical data sheets for our solutions.
Get the technical data sheet
